Research & Development

Chemical Research Laboratory,

the base of R&D

The purpose of the Chemical Research Laboratory is to engage in R&D, principally in the field of coal-chemistry, for the benefit of society. We work on developing new products at four R&D centers, focused on the fields of information technology, energy, and environment.

History
  • April 2006 Chemical Research Laboratory established
  • September 2009 New research building completed (Chiba City)

Chemical Products R&D Center

Here, we engage in R&D aimed at improving the characteristics of naphthalene and other light aromatic oils produced by distillation of coal tar, as well as heavy pitch for synthetic graphite electrodes used in electric furnaces for steelmaking.

Chemical Products R&D Center

Click here for more details

Coal tar pitch is a mixture of many aromatic compounds.
The Chemical Products R&D Center works towards product quality improvements by analyzing the chemical structure of pitch and evaluating its properties.

Analysis example
①Molecular weight distribution and chemical structure of pitch (analysis with LDI-MS)
①Molecular weight distribution and chemical structure of pitch (analysis with LDI-MS)

slide

slide

②Pitch properties measurement example (viscoelasticity measurement)
②Pitch properties measurement example (viscoelasticity measurement)

Stress

Strain

slide

Battery Materials R&D Center

This R&D center develops anode materials for rechargeable Li-ion batteries, using coal tar pitch as a raw material, and combining it with JFE Chemical’s unique reforming technologies.

Battery Materials R&D Center
Battery Materials R&D Center

Click here for more details

Coal tar pitch is an excellent raw material for manufacturing carbon materials.
Combining raw materials with suitable thermal reforming conditions makes it possible to control the crystal structure and shape of materials.
At the Battery Materials R&D Center, we take advantage of these characteristics to develop higher performance anode materials.

Spherulitic graphite example
①Manufacturing process
球晶黒鉛の例①製造プロゼス
球晶黒鉛の例①製造プロゼス
(2) Crystalline parameters and discharge capacity
球晶黒鉛の例(2) Crystalline parameters and discharge capacity

Fine Chemicals R&D Center

Here, we engage in the development of electronic materials, advanced functional resins, and other raw materials made from compounds with pentacyclic structures, such as indenes and fluorenes, which are characteristic and useful components of coal tar.

Cardo Structure

Click here for more details

We work on the development of various derivatives from fluorene, which has a pentacyclic structure.
We develop derivatives from compounds other than fluorene too, by taking advantage of their characteristic structure.

Fluorene derivative example
Fluorene derivative example

Magnetic Materials R&D Center

At this R&D center, we develop new materials from high-quality iron oxide raw materials obtained from steel-making processes. These include soft ferrite, for use as a magnetic core material for transformers and coils, and electromagnetic wave absorber ferrite magnetic powder.

Magnetic Materials R&D Center

Click here for more details

Mixing transition metal oxides with iron oxides and then applying a heat treatment to change the crystal structure makes the new material easily magnetizable in response to magnetic field changes.
The Magnetic Materials R&D Center aims at improving the magnetic characteristics of materials by optimizing mixture composition and heat treatment conditions.

Ferrite crystal structure and characteristics example
  • (1) X-ray diffraction
    (1) X-ray diffraction

    2 theta (deg.)

  • (2) Magnetic characteristics (B-H curve)
    (2) Magnetic characteristics (B-H curve)
  • (3) Ferrite crystal structure
    (3) Ferrite crystal structure

    Optical microscope image

    20 μm

  • SEM image

    SEM image

    10 μm
